进入系统视图
system-view
配置设备名
sysname RouterA
查看FLASH目录下内容
dir
指定下次启动配置文件
startup saved-configuration main.cfg
保存配置
save
重启
reboot
#置CONSOLE用户登陆的口令认证
system-view
[H3C]user-interface aux 0
[H3C-ui-aux0]authentication-mode password
[H3C-ui-aux0]set authenticaton password simple 123456
[H3C-ui-aux0]user privilege level 3
用户的命令控制级别设置
[H3C-ui-aux0]user privilege level 0
[H3C]super password level 1 simple 123456
[H3C]super password level 2 simple 123456
[H3C]super password level 3 simple 123456
# 设置super(明文)密码 当低权限向高权限切换时使用！
[RouterA]super password simple quidway
# 设置super(密文)密码
[RouterA]super password cipher quidway
# 启用telnet 管理功能
[RouterA]user-interface vty 0 4
[RouterA-ui-vty0-4]authentication-mode password
[RouterA-ui-vty0-4]set authentication password simple quidway
[RouterA-ui-vty0-4]user privilege level 3
[RouterA-ui-vty0-4]quit
[RouterA]telnet server enable
# 配置端口IP 地址
[RouterA]int e 0
[RouterA-Ethernet0]ip add 192.168.1.1 24
# 启动端口
[RouterA-Ethernet0]undo shutdown
[RouterA-Ethernet0]quit
# 保存,在任何视图下
save
# 查看当前设备配置信息
[RouterA]display current-configuration
# 查看Flash 中的配置(相当于CISCO start-config)
[RouterA]display saved-configuration
# 删除FLASH 中的配置信息(重置设备配置)
[RouterA]reset saved-configuration
# 重新启动设备
reboot
# 显示系统软件版本
[RouterA]display version
# 访问TFTP 服务器
tftp 服务器IP {put|get} 源文件名目的文件名
tftp 192.168.1.2 put startup.cfg startup.cfg //上传
tftp 192.168.1.2 get test.txt test.txt //下载
# 交换机IP 地址
[H3C]int vlan 1
[H3C-Vlan-interface1]ip add 192.168.1.1 24
[H3C-Vlan-interface1]undo ip add 192.168.1.1 24
# 创建VLAN
[H3C]vlan 10
[H3C]undo vlan 10
# 向VLAN 添加一个、多个端口
[H3C-vlan10]port e 1/0/1
[H3C-vlan10]port e 1/0/5 to e 1/0/7
[H3C-vlan10]port e 1/0/8 to e 1/0/9 e 1/0/11 to e 1/0/12
# 显示VLAN 信息
[H3C]dis vlan
# 设置以太网端口的链路类型为TRUNK
[H3C-Ethernet1/0/1]port link-type trunk
[H3C-Ethernet1/0/1]port trunk permit vlan all
[H3C-Ethernet1/0/1]port trunk pvid vlan 1
# 设置以太网端口的链路类型为ACCESS
[H3C-Ethernet1/0/1]port link-type access
[H3C-Ethernet1/0/1]port access vlan 10
[H3C-Ethernet1/0/1]undo port access vlan
# 配置Loopback 环回接口
[H3C]int loopback 0
[H3C-Lookback0]ip add 10.1.1.1 24
# 静态路由
[H3C]ip route 192.168.3.0 255.255.255.0 s 1/0
[H3C]undo ip route 192.168.3.0 255.255.255.0 s 1/0
# 默认路由
[H3C]ip route 0.0.0.0
